We offer the drone payload winch system supports third-party customized development and can be integrated into third-party drone ground or remote controllers. The following functions can be developed through the protocol:
(1) Supported control methods: SBUS, PWM, RS232/RS422,TTL
(2) Real-time information display: equipment working status, motor working status, input voltage, lowering rope length, retracting speed, motor speed, motor phase current, electric control unhooking device status, electric control unhooking device voltage, cumulative rope length used, cumulative number of fuses, cumulative number of overloads, system startup time, cumulative startup time, etc.
(3) Setting the fixed rope length for lowering/ascending: The lowering or ascension rope length can be set, and lowering/ascending can be performed with one-click.
(4) Setting the motor retracting speed: The lowering or ascension motor speed can be set.
The below is the screen shot of our communication protocol, if you want it, contact us by 18722591228@163.com.
